CMX88CS
Our Contractor CMX88CS 4K HDMI Matrix offers unprecedented performance and value for the custom installation market.
The CMX88CS supports HDMI2.0 with HDCP2.2, allowing distribution of eight HDMI sources to eight displays. This enables all sources to be viewed as required within a matrix configuration.
The unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 8-Way matrix also includes audio breakout, EDID management and a web browser interface module for control and configuration of the matrix.
CSC2000
| a wired chairman microphone unit designed for use with the CS2000 conference system. It features a 400 mm gooseneck electret condenser microphone with a cardioid polar pattern. The unit includes a built-in loudspeaker and dual 3.5 mm headphone connectors, each with volume control. On the control panel are a microphone ON/OFF push-button, a priority button (in the chairman version), a microphone gain control, and headphone volume control. The headphone output level is -8 dBV / +2 dBV, with an output impedance of 22 Ω. It connects via a 2 m cable terminated in a 7-pin DIN male plug and offers a 7-pin DIN female socket for daisy-chaining to further units. The unit’s frequency response is 50 Hz–18 kHz and the maximum SPL for 1 % THD is 125 dB. The unit operates within a temperature range from 0 °C to +40 °C, has net dimensions of 115 × 65 × 170 mm, and a net weight of approximately 1.1 kg. |
CSU2000
conference system control and power supply unit features a mains input of AC 100-240 V, 50/60 Hz, with a maximum current consumption of 1.0 A at 100 V or 0.42 A at 240 V. ManualsLib+1 It supplies DC power of +15 V and -7.5 V to connected microphone units. ManualsLib+1 The unit provides a comprehensive range of unbalanced line inputs (line, telephone coupling, insertion) with sensitivity of -14 dBV nominal / +11 dBV maximum and an input impedance of 33 k惟. ManualsLib Corresponding line outputs deliver -14 dBV nominal / +11 dBV maximum with an output impedance of 500 惟. ManualsLib It also accepts an external balanced microphone input with sensitivity of -56 dBV (-6 dBV via adapter), phantom power of 12 V 卤1 V. ManualsLib The unit can support up to 50 delegate/chairman microphone units in its standard configuration and up to 150 units when used with an optional extender board. Arco | Music+1 Physically, the unit measures 360 脳 90 脳 150 mm (WxHxD) and weighs approximately 1.80 kg. ManualsLib Its built-in MP3 recording capability via USB stick, LCD display for system status, test mode for microphone units, and connected headphone output makes it a full-featured conference system controlle
HD-MD4x2-4KZ-E
A high-performance 4K60 4:4:4 AV switcher. Provides four HDMI庐 inputs and two HDMI outputs. Includes support of HDR (High Dynamic Range) and Dolby Vision庐 video formats, automatic switching of HDMI inputs, advanced EDID management, native Crestron庐 control via Ethernet, XiO Cloud庐 connectivity, and enterprise-grade security.
LBB 3312/00 CCS Suitcase for 10 Delegate Units
The LBB 3312/00 CCS Suitcase for 10 Delegate Units is
used where CCS 800 Ultro contribution units will not be
used in one fixed location and, therefore, have to be easily
transportable. This is often the case in town halls, hotels,
business centers, local government offices or smaller halls
in major conference venues.
