MKR-LTG2-0IR
The MKR-LTG2-0IR Double Obstruction Light integrates
visible Red LED and Infrared Emitters into a double L-810(L).
Infrared energy (IR) can enhance compatibility for Aviator’s
Night Vision Imaging Systems (ANVIS) and Night Vision
Goggles (NVG). Precision molded Fresnel Optics produce a
low ground scatter tower lighting solution. Die cast aluminum
construction provides a 3/4 inch conduit hub for bottom
mounting. Multiple 9kA MOVs and 20kA gas plasma
discharge tubes provide robust surge suppression.
Description
Description
Features
– Integrated Infrared Emitters can enhance compatibility with Aviator’s Night vision Systems (ANVIS) and Night Vision Goggles (NVG).
– Rugged die cast aluminum construction.
– Stainless steel latches and hardware.
– 3/4 Inch conduit hub for bottom mounting.
– Modular replaceable power supplies.
-Power supplies operate from 100 to 240 Vac, 50/60Hz
-Power Factor Corrected (PFC), PF≥0.9 @ 120Vac
