QT607

Code Blue is the highest call system alert. Call Point Code Blue provides nursing staff with an immediate emergency call button. The location and code blue alert level is automatically broadcast across the nurse call system for priority actionCode Blue is the highest call system alert. Call Point Code Blue provides nursing staff with an immediate emergency call button. The location and code blue alert level is automatically broadcast across the nurse call system for priority action

Standard Call Point. A Call Point is required for every individual call location on the system. It features six levels of call, multi-colour re-assurance LED & ‘call follower’ sounder. The industry standard trigger socket will accept pear leads, pressure mats, portable radio triggers and a host of other triggering devices.

20 Zone Call Controller c/w 300mA PSU (Surface Version) 20 Zone Call Controller c/w 300mA PSU (Surface Version) Compatible with C-TEC’s entire range of 800 Series field devices. Housed in an attractive surface mounting plastic enclosure measuring just 214mm x 178mm Two call levels – standard (constant tone) and emergency (intermittent tone). Optional mute and call accept/reset buttons. ‘Call Accept’ functionality allows staff to send an intermittent call acknowledgment signal to calling zones to confirm help is on the way (dependent on wiring and field devices used). Includes a 12V 300mA PSU and 2 volt-free relay contacts which activate on a standard or emergency call.

Quantec Network Splitter An essential wiring/installation aid for C-TEC’s Quantec Addressable Call System. Helps protect against open and short circuit faults and reduces the risk of volt drop. Includes one input and one output connection for Quantec’s ‘Spine’ wiring (typically 1.5-2.5mm T&E) and six fused 400mA ‘limb’ connections for the wiring of individual circuits containing Quantec’s field devices (typically 4 core stranded security cable). At least one QT603 is required per Quantec system (the more you use, the easier it will be to program and fault-find). Install one QT603 per corridor junction (locate at the end of the corridor nearest to the Quantec Controller). If the corridor is longer than 50m, install the splitter in the centre of the corridor to reduce wiring runs. Mounts on a standard 25mm UK double gang back box. ‘Power’ and ‘Fault’ indicators. Max. 60 addressable devices per QT603.
